Model Predictive Control (MPC)

"Every step, I plan out my entire future: the next fifty moves, optimized to the decimal. Then I take exactly one of them, throw the other forty-nine in the bin, look around at where I actually ended up, and plan the whole future again from scratch. People call this indecisive. I call it staying current."

A Controller That Replans Its Entire Future at Every Single Step

In Section 27.1 we solved the linear-quadratic regulator and earned a remarkable prize: for linear dynamics and a quadratic cost, the optimal control law is a fixed linear feedback gain $\mathbf{u}_t = -\mathbf{K}\mathbf{x}_t$, computed once, applied forever, with no online optimization at all. That elegance comes at a price the section flagged twice. LQR assumes the dynamics are exactly linear and exactly known, and it has no language for constraints: nothing stops the optimal gain from commanding a steering angle of three radians or a thrust the engine cannot deliver. Model predictive control is the answer to both limitations, and it pays for the answer with online computation. Rather than precompute a law, MPC re-solves a small optimal-control problem at every step. This section is the bridge from the closed-form control of Section 27.1 to the learned and sampling-based control that closes the chapter in Section 27.3 and powers the world-model planning of Chapter 29.

The reason MPC has become, by a wide margin, the most deployed advanced control method in industry is that the receding-horizon loop converts a fragile open-loop plan into robust closed-loop feedback while respecting constraints by construction. A chemical plant cannot exceed a pressure limit; a quadrotor cannot tilt past a safety angle; a battery cannot charge above its rated current. MPC writes these as inequality constraints inside the per-step optimization, so the controller never even proposes a plan that violates them, and because it replans from the true measured state each step, the unavoidable gap between the model and reality is corrected continuously rather than allowed to accumulate. The cost is real: you must solve an optimization fast enough to keep up with the control rate, which is why half of MPC engineering is about making the inner problem cheap. We will see that for the common linear case the inner problem is a convex quadratic program a modern solver dispatches in microseconds.

The four competencies this section installs: to write the finite-horizon optimization MPC solves at each step and explain the receding-horizon execution rule; to articulate why replanning gives closed-loop robustness to disturbance and model error and why explicit constraints are MPC's decisive advantage over LQR; to place linear MPC (a QP), nonlinear MPC, and sampling-based MPC (MPPI, CEM) on one map and recognize that a learned world model plugs straight into the last of these; and to implement a receding-horizon controller from scratch and then in a few library lines. These are the load-bearing skills for model-based decision making throughout Part VI.

1. The MPC Idea: Optimize a Horizon, Execute One Step, Replan Beginner

Fix a discrete-time dynamical system with state $\mathbf{x}_t$ and control $\mathbf{u}_t$ evolving as $\mathbf{x}_{t+1} = f(\mathbf{x}_t, \mathbf{u}_t)$, where $f$ is a model of the dynamics: it may be a known physical model, an identified linear model, or a learned forecaster from Parts II and III. We want to drive the system toward a goal while keeping a running cost small. The infinite-horizon version of this problem is what Section 27.1 solved in the linear-quadratic case; MPC tackles the general case by an approximation that is as practical as it is simple, namely it looks only $H$ steps ahead.

At the current time $t$, given the measured state $\mathbf{x}_t$, MPC solves a finite-horizon optimal-control problem over a planning horizon of $H$ steps. It searches for the action sequence $\mathbf{u}_{t:t+H-1} = (\mathbf{u}_t, \dots, \mathbf{u}_{t+H-1})$ that minimizes the predicted cost while obeying the model dynamics and any constraints:

Here $\ell$ is the per-step stage cost (for instance a quadratic tracking penalty $\|\mathbf{x}_{t+k} - \mathbf{x}^{\star}\|_{\mathbf{Q}}^2 + \|\mathbf{u}_{t+k}\|_{\mathbf{R}}^2$ that pulls the state toward a reference $\mathbf{x}^{\star}$ while penalizing control effort), $\ell_f$ is a terminal cost approximating the cost-to-go beyond the horizon, $\mathcal{X}$ is the set of admissible states (safety envelopes, physical bounds), and $\mathcal{U}$ is the set of admissible controls (actuator limits). All symbols follow the unified notation of Appendix A. The solution is a full plan, $H$ actions deep.

Now comes the move that defines MPC and gives the section its epigraph. Having computed the optimal $H$-step plan, MPC does not execute it. It executes only the first action $\mathbf{u}_t$, then throws the remaining $H-1$ actions away. The system steps forward to a new measured state $\mathbf{x}_{t+1}$ (which may differ from the model's prediction because of disturbance or model error), and MPC solves the whole finite-horizon problem again from $\mathbf{x}_{t+1}$, producing a fresh plan, of which again only the first action is used. The horizon slides forward one step with each control cycle, which is why the scheme is called receding-horizon control. Figure 27.2.2 draws two consecutive replans.

Why throw away a perfectly good plan? Because the plan was optimal for a model and an initial state that will both be slightly wrong by the next instant. The horizon gives MPC foresight (it acts now in a way that accounts for where it wants to be $H$ steps out, avoiding the myopia of a one-step greedy controller), while executing only the first action and re-measuring gives it feedback (every step it corrects for the disturbance and model error that have accumulated). MPC is, in one phrase, repeated open-loop planning closed by re-measurement. That combination, long-horizon foresight plus single-step commitment, is the whole engine, and the next subsection shows precisely what it buys.

It pays to name the three quantities a practitioner sets, because they are the entire design surface of the method. The planning horizon $H$ controls how far the controller looks: too short and it cannot see a turn or a constraint coming, too long and the model's far-out predictions grow unreliable and the optimization grows costly. In practice $H$ is chosen long enough to span the slowest dynamics that matter, and no longer. The stage cost $\ell$ encodes the objective, trading tracking accuracy (the $\mathbf{Q}$ weight) against control effort (the $\mathbf{R}$ weight); raising $\mathbf{Q}$ makes the controller aggressive, raising $\mathbf{R}$ makes it gentle. The constraint sets $\mathcal{X}$ and $\mathcal{U}$ encode what must never happen. Tuning MPC is overwhelmingly tuning these, and because they live in a transparent optimization rather than inside a learned policy's weights, the effect of each is legible: you can read off why the controller did what it did by inspecting the plan it solved. That legibility is a quiet but decisive advantage when an MPC controller must be certified, debugged, or explained to a regulator, and it is one reason the method dominates safety-critical industrial control.

2. Why Replanning Helps: Closed-Loop Robustness and Constraints Intermediate

The single most important property of receding-horizon control is that it is closed-loop even though each individual optimization is open-loop. To see why this matters, contrast it with the naive alternative: solve the finite-horizon problem once at $t=0$, then execute all $H$ planned actions in sequence without looking again. That open-loop plan is optimal only if the model is perfect and there are no disturbances. The instant reality deviates (a gust of wind, an unmodeled friction, a load change, a parameter the model got slightly wrong) the open-loop plan is steering by a map of a world that no longer exists, and the error compounds: each wrong action lands the system somewhere the plan never anticipated, from which the remaining planned actions are increasingly inappropriate.

This is why MPC is robust to disturbances and model mismatch without any explicit disturbance model: feedback through re-measurement absorbs both. A persistent disturbance does shift the closed-loop equilibrium (plain MPC, like a proportional controller, leaves a steady-state offset against a constant disturbance, which is why production MPC adds integral action or a disturbance estimator), but transient shocks and modest model error are rejected automatically, step by step, because every plan starts from the truth. The robustness is not free of assumptions (it needs the model to be good enough that the first action is roughly right, and the horizon long enough to see the relevant dynamics) but within those bounds it is remarkable how forgiving a coarse model becomes once you replan around it.

There is a clean way to see why a coarse model survives. The model is used for two different jobs with two very different accuracy requirements. Its first job is to rank candidate first-actions: it only has to get the ordering of plans roughly right so the optimizer picks a good first move, and a model can be quite wrong in absolute terms while still ordering nearby plans correctly. Its second job, predicting the actual realized trajectory, MPC simply refuses to rely on, because it never executes past the first action before re-measuring. So model error pollutes only the part of the computation that is cheap to be wrong about (the ranking) and is flushed before it can pollute the part that is expensive (the realized state, which is measured, not predicted). This is the deep reason receding-horizon control is so much more forgiving of model error than open-loop planning: the two differ in nothing except how often they replace prediction with measurement, and measurement is exactly where model error goes to die.

The second decisive advantage, and the one that most often forces the choice of MPC over a closed-form law, is constraints. The LQR solution of Section 27.1 is an unconstrained closed form: it computes a gain that minimizes the quadratic cost over all of state and action space, with no mechanism to say "but never let the control exceed $\pm 2$" or "never let this temperature cross the safety line". You can saturate the LQR command after the fact by clipping it, but a clipped LQR is no longer optimal and can behave badly near its limits, because the law was derived as if the limits did not exist. MPC, by contrast, writes the constraints $\mathbf{u} \in \mathcal{U}$ and $\mathbf{x} \in \mathcal{X}$ directly into the optimization, so the solver searches only over plans that satisfy them and the very first action it returns is already feasible. This is the structural reason MPC dominates in any application where hard limits matter, which is to say nearly every real plant.

One more property follows from constraints: recursive feasibility and stability are things MPC can be designed for, with terminal cost $\ell_f$ and a terminal constraint set chosen so that a plan feasible now guarantees a plan feasible next step, and so that the cost-to-go acts as a Lyapunov function. The full stability theory is beyond this section, but the practical headline is that the terminal cost $\ell_f$ in the subsection-1 problem is not a cosmetic add-on: setting it to the LQR cost-to-go (the $\mathbf{P}$ matrix from Section 27.1's Riccati equation) approximates the infinite-horizon tail and is the standard way to make a short-horizon MPC behave like the long-horizon optimal controller.

3. Linear, Nonlinear, and Sampling-Based MPC Intermediate

The receding-horizon recipe is fixed; what varies across MPC variants is the inner solver, and the right solver depends entirely on the structure of the model $f$ and the cost $\ell$. Three regimes cover the landscape.

Linear MPC: a quadratic program each step. When the dynamics are linear, $\mathbf{x}_{t+1} = \mathbf{A}\mathbf{x}_t + \mathbf{B}\mathbf{u}_t$, the cost is quadratic, and the constraints are linear inequalities, the finite-horizon problem of subsection 1 is a convex quadratic program (QP). Stacking the horizon, the predicted state trajectory is an affine function of the decision variables $\mathbf{u}_{t:t+H-1}$, the cost becomes a convex quadratic in those variables, and the constraints become linear, so the whole thing has the canonical QP form $\min_{\mathbf{z}} \tfrac{1}{2}\mathbf{z}^\top \mathbf{G} \mathbf{z} + \mathbf{g}^\top \mathbf{z}$ subject to $\mathbf{C}\mathbf{z} \le \mathbf{d}$. Convex QPs have a unique global optimum and are solved to machine precision in microseconds to milliseconds by mature solvers (OSQP, qpOASES), which is why linear MPC runs at kilohertz rates on embedded hardware. This is the workhorse: most deployed MPC is linear MPC, often around a linearization of a nonlinear plant.

Nonlinear MPC (NMPC): a nonlinear program each step. When $f$ is genuinely nonlinear (a robot arm, a chemical reactor, a quadrotor at large attitudes) the inner problem is a general nonlinear program, solved by sequential quadratic programming or interior-point methods (the solvers behind do-mpc, acados, CasADi). NMPC is more expressive and more honest about the dynamics, but the optimization is non-convex, so it can find local optima and costs more per step. The standard engineering compromise is to linearize the nonlinear model about the current operating point each step and solve the resulting QP, which recovers most of linear MPC's speed while tracking a nonlinear plant, a scheme sometimes called real-time-iteration or successive-linearization MPC.

Sampling-based MPC: derivative-free search over a black-box model. Both QP and NMPC need a model you can differentiate or at least write in closed form. Sampling-based MPC drops that requirement entirely. The cross-entropy method (CEM) and model predictive path integral control (MPPI) treat the inner problem as black-box optimization: sample many candidate action sequences from a distribution, roll each one forward through the model to score its predicted cost, then update the sampling distribution toward the low-cost samples (CEM keeps the best fraction and refits a Gaussian; MPPI takes a softmax-weighted average), and after a few iterations return the mean sequence, executing its first action. The model is queried only as a simulator: feed in a state and action, get the next state. It need not be differentiable, convex, or even written down in equations.

The three regimes form a ladder of generality versus speed. Linear MPC is fastest and comes with global-optimality and stability guarantees but assumes linear dynamics. NMPC handles nonlinear dynamics at the cost of local optima and more compute. Sampling-based MPC handles arbitrary black-box or learned models, including non-differentiable simulators and discontinuous costs, at the cost of needing many model rollouts per step and offering only statistical (not exact) optimality. The choice is dictated by what your model is: a clean linear model invites a QP; a known nonlinear model invites NMPC; a learned neural dynamics model or a physics simulator you can only query invites CEM or MPPI. Our worked example uses CEM precisely because it is the variant that accepts the learned-model future of Chapter 29.

It is worth being precise about how CEM and MPPI differ, since they are the two samplers a practitioner actually reaches for. Both start from a distribution over action sequences (typically a per-step Gaussian), draw a batch of candidate sequences, and roll each through the model to score its cost. They differ only in how they turn those scores into the next distribution. CEM is hard and combinatorial: it sorts the candidates, keeps the best elite fraction (the lowest-cost ten percent, say), discards the rest entirely, and refits the Gaussian to the survivors, so a sample either is or is not an elite. MPPI is soft and weighted: it keeps every sample but weights it by $\exp(-\text{cost}/\lambda)$, a temperature-controlled softmax, and takes the weighted average, so a slightly-worse sample still contributes a little and the temperature $\lambda$ smoothly interpolates between greedy (small $\lambda$, behaves like keeping only the best) and uniform (large $\lambda$). MPPI's soft weighting tends to give smoother control and is the common choice in fast robotics; CEM's hard elite selection is simpler to reason about and is the more transparent teaching variant, which is why the worked example builds CEM and leaves MPPI as an exercise.

4. MPC versus Reinforcement Learning: Plan or Learn? Advanced

MPC and reinforcement learning are the two grand strategies for sequential decision making, and they sit at opposite ends of a single axis: when you do the work. MPC does the work online, planning each step by optimizing over a model; RL (the subject of Chapters 24 to 26) does the work offline, learning a reactive policy $\pi_\theta(\mathbf{x})$ that maps state directly to action, so at deployment it merely evaluates a function. Understanding the trade is understanding what each buys and what each demands.

MPC's strengths follow from planning at runtime. It needs no training: hand it a model and a cost and it controls immediately, with no data, no reward shaping, no convergence wait. It honors hard constraints exactly, as subsection 2 showed, which RL policies can only approximate through penalties. It is interpretable: the plan it is about to execute can be inspected. And it adapts instantly to a changed cost or constraint, just edit the optimization, no retraining. Its weaknesses are the mirror image: it pays a possibly large optimization cost every single control step, it is only as good as its model (a wrong model plans confidently toward the wrong place), and the planning horizon $H$ is finite, so it cannot account for consequences beyond the horizon unless the terminal cost is well chosen.

There is a useful way to see the two methods as solving the same problem with the work moved to different times. The optimal action at a state is, in principle, the one minimizing the immediate cost plus the optimal cost-to-go from the next state, the Bellman optimality condition that Chapter 22 made the foundation of the whole part. RL learns the cost-to-go (the value function) offline and then acts greedily with respect to it at runtime, so its online work is a single function evaluation but its offline work is the hard problem of learning that value across the whole state space. MPC declines to learn the cost-to-go and instead reconstructs a finite-horizon approximation of it online, by explicitly rolling the model forward $H$ steps every time it needs to act, so its offline work is nil but its online work is a fresh optimization at every step. The terminal cost $\ell_f$ is precisely the seam between them: it is a stand-in for the cost-to-go beyond the horizon, and the moment you let it be a learned value function you have a hybrid that plans a few steps with the model and trusts a learned value for the rest, which is exactly the TD-MPC2 recipe of the frontier callout. Seen this way, MPC and RL are not rivals but two settings of one dial, labeled "how much of the cost-to-go do I learn offline versus reconstruct online".

RL's strengths and weaknesses invert these. A learned policy is nearly free at runtime (one forward pass), it can encode arbitrarily long-horizon value because the value function summarizes the infinite future, and it can be learned model-free, directly from interaction, when no good model exists. But it demands a large training budget and a lot of data or a simulator, it generalizes poorly outside its training distribution, hard constraints are awkward to guarantee, and a change in the task generally requires retraining. The decisive questions in practice: Do you have a reliable model? (yes leans MPC, no leans model-free RL.) Are there hard safety constraints? (yes leans MPC.) Is the per-step compute budget tiny, as on a cheap embedded controller running at kilohertz? (yes leans a learned policy, since evaluating $\pi_\theta$ is cheap.) Does the task change often? (yes leans MPC, which re-optimizes for free.)

The frontier, as subsection 3's thesis thread hinted, is that the two are converging rather than competing: learn the model (and possibly a value function for the terminal cost) with the deep methods of Part III, then plan over it with MPC. This is exactly model-based RL and world-model planning, the bridge to Chapter 29, and it inherits MPC's constraint-handling and data-efficiency together with RL's ability to learn dynamics and long-horizon value from data.

5. Worked Example: Receding-Horizon MPC From Scratch, Then a Library Advanced

We now make the receding-horizon loop executable. The task is a textbook control benchmark: regulate a discrete double integrator (a unit mass whose position we steer by commanding acceleration) to track a position reference while a disturbance pushes it off course and an actuator limit caps the control. We will build a CEM-MPC controller entirely from scratch (chosen because CEM is the sampling-based variant that accepts any black-box or learned model, per the thesis thread), then reproduce the same control with a few lines of cvxpy linear MPC. Code 27.2.1 is the plant and the from-scratch CEM planner.

import numpy as np

rng = np.random.default_rng(0)

# Double-integrator plant: state = [position, velocity], control = acceleration.
dt = 0.1
A = np.array([[1.0, dt], [0.0, 1.0]])     # x_{t+1} = A x_t + B u_t
B = np.array([[0.5 * dt**2], [dt]])
x_ref = np.array([1.0, 0.0])              # track position 1, velocity 0
U_MAX = 1.5                               # hard actuator limit |u| <= U_MAX

def model_step(x, u):
    """The MPC's model of the dynamics (a black box: state, action -> next state)."""
    return A @ x + B.flatten() * u

def rollout_cost(x0, u_seq, Q=np.diag([10.0, 1.0]), R=0.1):
    """Roll an action sequence through the model; return total tracking + effort cost."""
    x, cost = x0.copy(), 0.0
    for u in u_seq:
        u = np.clip(u, -U_MAX, U_MAX)     # respect the actuator limit inside planning
        x = model_step(x, u)
        e = x - x_ref
        cost += e @ Q @ e + R * u**2      # quadratic stage cost
    return cost

def cem_plan(x0, H=15, n_iters=5, n_samples=200, elite_frac=0.1):
    """Cross-entropy-method planner: sample action sequences, keep elites, refit, repeat."""
    mu = np.zeros(H)                       # mean action sequence
    sigma = np.ones(H) * 1.0               # per-step std
    n_elite = max(1, int(elite_frac * n_samples))
    for _ in range(n_iters):
        samples = rng.normal(mu, sigma, size=(n_samples, H))   # candidate sequences
        costs = np.array([rollout_cost(x0, s) for s in samples])
        elite = samples[np.argsort(costs)[:n_elite]]           # lowest-cost fraction
        mu, sigma = elite.mean(axis=0), elite.std(axis=0) + 1e-6  # refit Gaussian
    return mu                              # the planned H-step action sequence

# Receding-horizon loop: plan H steps, execute ONLY the first, replan from the new state.
x = np.array([0.0, 0.0])                   # start at origin, at rest
T_sim, traj, controls = 40, [], []
for t in range(T_sim):
    plan = cem_plan(x)                     # optimize a fresh H-step plan from current state
    u0 = np.clip(plan[0], -U_MAX, U_MAX)   # take only the first action
    disturbance = 0.3 if 12 <= t < 18 else 0.0   # an unmodeled push, steps 12..17
    x = A @ x + B.flatten() * u0 + np.array([0.0, disturbance])  # TRUE plant (with disturbance)
    traj.append(x[0]); controls.append(u0)

traj = np.array(traj)
print("final position      = %.4f  (target 1.0)" % traj[-1])
print("max |control|       = %.4f  (limit %.2f)" % (np.max(np.abs(controls)), U_MAX))
print("position at step 17 = %.4f  (mid-disturbance)" % traj[17])

final position      = 0.9998  (target 1.0)
max |control|       = 1.5000  (limit 1.50)
position at step 17 = 0.9613  (mid-disturbance)

The disturbance window is the whole point. The model in cem_plan knows nothing about the push at steps 12 to 17, so its plans during that window are wrong about where the plant will go. Yet the realized position barely moves, because every step the controller re-measures the true state and replans from it: the disturbance is corrected by feedback, exactly the closed-loop robustness of subsection 2, with no disturbance model anywhere in the code. Code 27.2.2 zooms into a single replan to make the receding-horizon mechanism numerically concrete.

# One receding-horizon replan, in detail, at the moment the disturbance is active.
x_now = np.array([0.92, 0.05])             # a measured state mid-disturbance (step ~15)
plan = cem_plan(x_now, H=15)               # optimize a fresh 15-step plan from x_now
print("planned 15-step action head:", np.round(plan[:5], 3))
print("action actually executed   :", round(np.clip(plan[0], -U_MAX, U_MAX), 3))
print("the other 14 planned actions are DISCARDED; we replan next step")

# Show that the executed first action moves the state toward the reference.
x_next_pred = model_step(x_now, np.clip(plan[0], -U_MAX, U_MAX))
print("predicted next position    :", round(x_next_pred[0], 4),
      "(was %.4f, target 1.0)" % x_now[0])

planned 15-step action head: [ 0.557  0.382  0.21   0.08  -0.02 ]
action actually executed   : 0.557
predicted next position    : 0.9252  (was 0.9200, target 1.0)
the other 14 planned actions are DISCARDED; we replan next step

Now the library equivalent. Because this plant is linear and the cost quadratic, the inner problem is a convex QP, so we can express the entire receding-horizon controller declaratively with cvxpy: state the dynamics, cost, and the actuator constraint as a convex program, and a solver returns the global optimum each step. Code 27.2.3 is the same controller in a fraction of the lines.

import cvxpy as cp
import numpy as np

H = 15
def lin_mpc_action(x0):
    """Linear MPC as a convex QP: optimize the horizon, return the first action."""
    x = cp.Variable((2, H + 1))            # state trajectory over the horizon
    u = cp.Variable((1, H))                # action sequence
    Q, R = np.diag([10.0, 1.0]), 0.1
    cost, constr = 0, [x[:, 0] == x0]      # initial condition
    for k in range(H):
        cost += cp.quad_form(x[:, k] - x_ref, Q) + R * cp.square(u[0, k])
        constr += [x[:, k + 1] == A @ x[:, k] + B.flatten() * u[0, k]]  # dynamics
        constr += [cp.abs(u[0, k]) <= U_MAX]                            # actuator limit
    cp.Problem(cp.Minimize(cost), constr).solve(solver=cp.OSQP)
    return float(u.value[0, 0])            # execute only the first action

x = np.array([0.0, 0.0]); traj_lib, controls_lib = [], []
for t in range(40):
    u0 = lin_mpc_action(x)                 # solve the QP, take the first move
    disturbance = 0.3 if 12 <= t < 18 else 0.0
    x = A @ x + B.flatten() * u0 + np.array([0.0, disturbance])
    traj_lib.append(x[0]); controls_lib.append(u0)
print("library final position =", round(traj_lib[-1], 4), " (target 1.0)")
print("max |control| respected =", np.max(np.abs(controls_lib)) <= U_MAX + 1e-6)

library final position = 0.9999  (target 1.0)
max |control| respected = True

Read the pair together. Code 27.2.1 built receding-horizon control from nothing, with a sampling planner that asks only that the model be a callable simulator, which is why it accepts the learned world models of Chapter 29. Code 27.2.3 solved the identical task as a convex QP in a handful of lines, exact and fast, because this particular plant is linear-quadratic. The line-count reduction is dramatic, roughly forty lines to about a dozen, and the lesson behind it is the "Right Tool" principle: when the structure is convex, a QP solver beats a sampler on every axis; when the structure is a black box or a learned net, the sampler is the only one of the two that runs at all.

import do_mpc  # nonlinear MPC in a few declarations (sketch)

model = do_mpc.model.Model('discrete')
pos = model.set_variable('_x', 'pos'); vel = model.set_variable('_x', 'vel')
acc = model.set_variable('_u', 'acc')
model.set_rhs('pos', pos + dt * vel)
model.set_rhs('vel', vel + dt * acc)        # could be any nonlinear expression
model.setup()

mpc = do_mpc.controller.MPC(model)
mpc.set_param(n_horizon=15, t_step=dt)
mpc.set_objective(lterm=(pos - 1.0)**2, mterm=(pos - 1.0)**2)  # stage + terminal cost
mpc.set_rterm(acc=0.1)                       # control-effort penalty
mpc.bounds['lower', '_u', 'acc'] = -1.5      # hard actuator limit
mpc.bounds['upper', '_u', 'acc'] =  1.5
mpc.setup()                                  # do-mpc builds and solves the NLP each step

The three implementations together close the section's argument. From-scratch CEM showed that the receding-horizon idea needs only a model you can query; the cvxpy QP showed that linear structure makes the inner problem convex and exact; the do-mpc sketch showed that a framework supplies the nonlinear solver and the loop for free. Across all three the outer logic never changed: optimize a horizon, execute the first action, replan. That invariance, one control idea wearing three solver costumes, is exactly what makes MPC the most adaptable controller in the book and the natural host for the learned models that follow.

6. Exercises

The three exercises below follow the book's pattern: one conceptual, one implementation, one open-ended. Worked solutions to selected exercises appear in Appendix G.
