Counterfactual and What-If Analysis

"Give me the world as it was the morning of the decision, and I will run it forward twice: once as it happened, and once as it might have. The gap between my two endings is the only thing anyone ever wanted from me, and it is the one number I can never check."

A Model Replaying History With One Decision Changed

In Section 30.2 the $\operatorname{do}$-operator let us state interventions, asking what happens to the system if we reach in and set a variable; in Section 30.3 we estimated their population-average effect, an interventional distribution averaged over a population. That is the second rung of Pearl's ladder. This section climbs the third and final rung. The interventional question "what is $\mathbb{E}[Y \mid \operatorname{do}(X = x)]$" speaks about a hypothetical population of units all forced to $X = x$. The counterfactual question is narrower and stranger: take this patient, who actually received treatment $X = 1$ and whose blood pressure we actually watched fall, and ask what their blood pressure would have been had they instead received $X = 0$, holding fixed everything idiosyncratic about them that we cannot see. We are conditioning on a realized outcome and then contradicting part of the history that produced it. That is why counterfactuals sit above interventions: every counterfactual query implies an interventional one (marginalize away the conditioning and you get back the $\operatorname{do}$ expression), but the reverse fails: two systems can share every interventional distribution and still disagree about what would have happened to a specific unit.

We use the unified notation of Appendix A throughout: $\mathbf{x}_t$ the observed covariates, $a_t$ the action or treatment, $y_t$ the outcome of interest, $\mathbf{u}$ the exogenous noise that a structural causal model treats as the seed of a particular history. The reason counterfactual reasoning deserves its own section, rather than a footnote to intervention, is that almost every high-stakes use of a temporal model is secretly counterfactual. "Did the marketing campaign work" is a question about what sales would have been without it. "Should we have throttled that service earlier" is a question about an outage that would not have happened. "Was the treatment responsible for the recovery" is a question no controlled trial on this one patient can answer. The model becomes a device for replaying a recorded history with one decision changed, and the value it produces is the difference between the two replays.

The three competencies this section installs are these: to state and apply the abduction-action-prediction recipe over a structural causal model, deriving a unit-level counterfactual rather than a population intervention; to recognize the three temporal forms of counterfactual question (counterfactual forecasting, retrospective what-if, off-policy evaluation) and match each to a method family; and to build a counterfactual baseline from scratch as a fitted state-space model and then reproduce it with a production library, while never forgetting the fundamental problem of causal inference that no amount of modeling repeals.

1. The Top Rung: Counterfactuals and the Abduction-Action-Prediction Recipe Intermediate

A counterfactual is a query about a specific realized unit. Formally, it asks for the distribution of an outcome $Y$ under a hypothetical action, given that we observed the unit's actual covariates and actual outcome under the action it really received. The notation makes the layering visible: $\mathbb{P}\big(Y_{a'} = y' \mid X = x,\, A = a,\, Y = y\big)$ reads "the outcome $Y$ would have been $y'$ under action $a'$, given that we saw covariates $x$, the unit actually took action $a$, and we observed outcome $y$." The subscript $a'$ on $Y$ is the counterfactual action; everything after the conditioning bar is the world that actually happened. Contrast this with the interventional query (the $\operatorname{do}$-operator of Section 30.2, estimated in Section 30.3), $\mathbb{E}[Y \mid \operatorname{do}(A = a')]$, which has no conditioning on a realized outcome at all: it averages over the whole population, while the counterfactual fixes one unit's history and edits it.

The engine that answers such queries is the structural causal model (SCM). An SCM specifies each variable as a deterministic function of its causal parents and an exogenous noise term: $V_i = f_i(\mathrm{pa}_i, U_i)$, where $\mathrm{pa}_i$ are the parents of $V_i$ in the causal graph and $U_i$ is independent exogenous noise. The noise $\mathbf{u} = (U_1, \dots, U_n)$ is the entire idiosyncrasy of a unit: fix $\mathbf{u}$ and the whole history is determined; draw a fresh $\mathbf{u}$ and you get a different unit. This is precisely the handle a counterfactual needs, because "this particular unit" just means "this particular value of $\mathbf{u}$." The counterfactual recipe is the three-step procedure that recovers and reuses that noise:

• Abduction. Given the observed evidence $E$ (the unit's actual covariates and outcome), infer the posterior over the exogenous noise, $\mathbb{P}(\mathbf{u} \mid E)$. This is the step that personalizes the model to the one unit we are asking about: it answers "what latent seed must this unit have had, to have produced the history we saw."
• Action. Apply the intervention $\operatorname{do}(A = a')$ to the SCM, which surgically replaces the structural equation for $A$ with the constant $a'$ and severs $A$ from its parents, exactly the graph surgery of the $\operatorname{do}$-operator (Section 30.2). Crucially, every other structural equation is left untouched.
• Prediction. Re-run the modified SCM forward, but using the noise drawn from the abduction posterior $\mathbb{P}(\mathbf{u} \mid E)$ rather than the prior. The resulting distribution of $Y$ is the counterfactual answer.

The conceptual payoff is that abduction is the entire difference between a counterfactual and an intervention. An intervention runs the surgically modified model forward with noise drawn from the prior, so it averages over all possible units; a counterfactual runs the same modified model forward with noise drawn from the posterior given the evidence, so it speaks about the one unit whose history pinned that noise down. The action and prediction steps are shared; abduction is what climbs the ladder. Figure 30.4.1 lays out the three steps as a pipeline from observed world to counterfactual world.

To make the recipe concrete, take a one-variable linear-Gaussian example. Suppose the outcome follows $Y = \beta A + U$ with $U \sim \mathcal{N}(0, \sigma^2)$, and we observe a unit that took action $A = a$ and produced outcome $Y = y$. Abduction is trivial here because the structural equation is invertible: given $A = a$ and $Y = y$, the noise is pinned to exactly $U = y - \beta a$, with no residual uncertainty. Action sets $A = a'$. Prediction re-runs the equation with the recovered noise held fixed: $Y_{a'} = \beta a' + U = \beta a' + (y - \beta a) = y + \beta(a' - a)$. The counterfactual outcome is the observed outcome shifted by $\beta$ times the change in action. That last expression is the heart of unit-level counterfactual reasoning: it does not predict $y'$ from scratch, it edits the realized $y$ by the structural effect of the action change, preserving everything idiosyncratic ($U$) about the unit. The numeric callout walks one such edit end to end.

2. Counterfactuals in Time Series: Three Temporal Forms Intermediate

The abduction-action-prediction recipe is stated for a static SCM, but the questions practitioners actually ask are temporal, and they come in three recognizable shapes. Each is the same recipe with the noise and the edited action living at different points on a timeline.

The first is counterfactual forecasting: we ran an intervention at some point in the past (a marketing campaign launched, a price changed, a policy enacted) and we want the trajectory the outcome would have followed had we not intervened. The structure is a pre-intervention period in which the system evolved untreated, an intervention time $t^{*}$, and a post-intervention period in which we observe the actual treated trajectory $y_t$ for $t \ge t^{*}$ but want the counterfactual untreated trajectory $y_t^{(0)}$. Abduction here means fitting a model on the pre-intervention period so it captures the unit's own dynamics and its relationship to unaffected control series; prediction means rolling that model forward through the post-period as if no intervention had occurred. The counterfactual effect is the running gap $y_t - y_t^{(0)}$, and its cumulative sum is the total causal impact. This is exactly the question that motivates the CausalImpact methodology of subsection three.

The second is retrospective what-if for a past decision: a decision was made at time $t^{*}$ (a clinician escalated care, a trader hedged, an operator failed to restart a service) and afterward we want to know what the trajectory would have been under the alternative decision. The difference from counterfactual forecasting is one of framing rather than mechanics: forecasting asks about the absence of an action that happened, retrospective what-if asks about the presence of an action that did not. Both reduce to the same recipe: abduct the unit's noise from its realized history, apply $\operatorname{do}$ of the alternative decision at $t^{*}$, predict forward with the noise held fixed.

The third is off-policy counterfactual evaluation of agents, which is where this section reconnects to Part VI. An agent followed some behavior policy and generated a logged trajectory of states, actions, and rewards; we want to evaluate a different target policy without ever deploying it, by asking "what return would this agent have earned had it followed the target policy on these same situations." This is the off-policy evaluation problem of Section 24.3 and the offline reinforcement learning setting of Section 26.2, viewed through the counterfactual lens: the logged episodes are the observed evidence, the target policy's actions are the counterfactual $\operatorname{do}$, and the estimated return is a counterfactual prediction. Importance-weighting estimators reweight logged outcomes by the probability ratio of target to behavior policy, which is one concrete way to perform the abduction-and-prediction without an explicit SCM. Figure 30.4.2 places the three forms on a common timeline.

3. Methods: Structural Abduction, CausalImpact Baselines, and Deep Counterfactual Models Advanced

Three method families answer temporal counterfactual questions, ordered roughly from most assumption-heavy and most interpretable to most flexible and most opaque.

Structural-model abduction is the direct implementation of subsection one: write down an explicit SCM for the system, invert (or do Bayesian inference over) the structural equations to recover the exogenous noise from the observed evidence, edit the action, and re-run. When the structural equations are invertible (as in the linear-Gaussian example) abduction is exact; when they are not, abduction becomes posterior inference over $\mathbf{u}$, and the counterfactual is a distribution rather than a point. This family is the gold standard when you genuinely know the mechanism, and it degrades exactly as far as your structural assumptions are wrong.

CausalImpact-style counterfactual baselines sidestep the need for a full mechanistic SCM by treating counterfactual forecasting as a prediction problem with a structural-time-series model. The idea, due to Brodersen and colleagues at Google, is to fit a Bayesian structural time-series model (a state-space model with trend, seasonality, and regression on a set of control series that were not affected by the intervention) on the pre-intervention period, then forecast it forward through the post-period. That forecast is the counterfactual "what would have happened without the intervention," and the difference between observed and forecast, with full posterior credible intervals, is the estimated causal effect. The controls do the heavy lifting: they must track the target through the same external shocks the target experiences, while themselves being immune to the intervention, so that any post-period divergence is attributable to the intervention and not to a common shock. This is the workhorse for marketing, policy, and product launches, and it is the library we reproduce in subsection five.

Deep counterfactual models learn the counterfactual mapping directly with neural networks, trading interpretability for flexibility and the ability to handle high-dimensional confounders and time-varying treatments. The Counterfactual Recurrent Network (Bica et al., 2020) and the Causal Transformer (Melnychuk et al., 2022) estimate counterfactual outcomes of treatment sequences while using balancing or adversarial objectives to remove the time-varying confounding that ordinary sequence models would otherwise absorb as spurious treatment effect. These methods shine when treatments and confounders are themselves sequences (a dosing schedule responding to evolving vitals), the regime where a fixed structural model is hopeless and a naive forecaster is biased.

All three families collide with the same immovable obstacle, the fundamental problem of causal inference: for any single unit we observe the outcome under exactly one action, never both. The patient who was treated did not also go untreated; the market that saw the campaign did not also go without it. The counterfactual outcome $y_t^{(0)}$ is, by construction, never observed for the unit that received the intervention, so the gap $y_t - y_t^{(0)}$ that we report can never be directly checked against ground truth for that unit. Every method above is a strategy for imputing the missing potential outcome from assumptions (an SCM's structure, the controls' immunity, a network's learned regularities), and every counterfactual number is only as trustworthy as the assumption that filled the unobserved slot. This is not a limitation we engineer away; it is the definition of the problem.

4. Uses, and the Risk of Over-Trusting Model-Based Counterfactuals Intermediate

The three running domains of this book each have a signature counterfactual question, and each carries its own characteristic way of going wrong.

In healthcare, the counterfactual is the patient trajectory under an alternative treatment: what would this patient's vitals have done had we not started the vasopressor, had we extubated a day earlier, had we held the antibiotic. These power individualized treatment-effect estimation and retrospective case review, and they are exactly the time-varying-treatment regime the deep counterfactual models of subsection three were built for, because the confounders (a clinician escalates care because the patient is deteriorating) are themselves evolving in time. The risk is that the confounding is rarely fully observed, so a model that looks accurate on logged data can attribute to the treatment an effect that was really the clinician's hidden information about prognosis.

In finance, the counterfactual is the market scenario under an untaken decision: what would the portfolio have done had we not hedged, what would volatility have looked like absent the intervention, what is the counterfactual loss of the strategy we did not run. These feed scenario analysis and attribution. The risk is regime change: the pre-period relationship between the target and its controls, on which the counterfactual baseline rests, can break precisely at the moment of interest, so the "what would have happened" line is extrapolating a correlation that no longer holds.

In sensor and operations, the counterfactual is the root-cause what-if for an outage: what would system latency have been had we throttled the failing node earlier, had we not deployed the bad config, had the autoscaler fired. These drive blameless postmortems and what-if remediation planning. The risk is the seductiveness of a clean story: a model will always produce a counterfactual, and a plausible-looking gap can manufacture a root cause that was actually a coincidence of a common upstream shock.

Across all three, the unifying danger is over-trusting a model-based counterfactual. Because the counterfactual outcome is never observed (subsection three), the model's confidence interval is a statement about the model's own uncertainty under its assumptions, not about whether those assumptions hold. A counterfactual can be precise and wrong: tight credible intervals around a baseline whose controls were secretly affected by the intervention, or a deep model confident in a treatment effect that is really unobserved confounding. The discipline that separates a useful counterfactual from a dangerous one is sensitivity analysis: vary the assumptions (drop a control, perturb the SCM, test alternative confounding structures) and report how much the conclusion moves. A counterfactual that survives that stress test is evidence; one that collapses under it was a story the model told to fill a blank it could never fill from data.

5. Worked Example: A Counterfactual Trajectory From Scratch, Then by Library Advanced

We now build a counterfactual baseline end to end. The setup is the counterfactual-forecasting form of subsection two: a target series that experiences an intervention partway through, plus a control series that tracks the target but is immune to the intervention. We fit a structural model on the pre-intervention period only, forecast the counterfactual "no-intervention" trajectory through the post-period, and compare it to the actual treated trajectory to recover the causal effect. Code 30.4.1 generates the data and fits a from-scratch local-level state-space model (the same Kalman-filter machinery of Section 7.6) with a regression on the control, then predicts the counterfactual.

import numpy as np

rng = np.random.default_rng(7)
T, t_star = 120, 80                     # total steps; intervention starts at t_star

# A control series (immune to the intervention) and a target driven by it plus noise.
control = np.cumsum(rng.normal(0, 1.0, size=T)) + 50.0      # a random-walk control
beta_true, level_true = 0.8, 5.0                            # target = level + beta*control + noise
noise = rng.normal(0, 0.7, size=T)
target = level_true + beta_true * control + noise
effect_true = 6.0                                            # the intervention adds +6 after t_star
target[t_star:] += effect_true                              # inject the causal effect

def fit_counterfactual(target, control, t_star):
    """Fit level + beta*control on the PRE period via a local-level state-space model,
    then roll forward to predict the no-intervention counterfactual over the POST period."""
    pre_y, pre_x = target[:t_star], control[:t_star]
    # Regress target on control over the pre-period (abduction of the structural relation).
    X = np.vstack([np.ones(t_star), pre_x]).T
    coef, *_ = np.linalg.lstsq(X, pre_y, rcond=None)         # [level_hat, beta_hat]
    level_hat, beta_hat = coef
    resid = pre_y - (level_hat + beta_hat * pre_x)           # pre-period residual (the unit's noise)
    # Local-level Kalman smoothing of the residual gives a slowly-varying offset; here it is ~0 mean.
    offset = resid.mean()                                    # held-fixed idiosyncratic level (abduction)
    # Prediction: re-run the fitted relation forward over the POST period with control as-is.
    cf = level_hat + beta_hat * control + offset             # counterfactual no-intervention trajectory
    return cf, level_hat, beta_hat

cf, level_hat, beta_hat = fit_counterfactual(target, control, t_star)
gap = target - cf                                            # running counterfactual effect
cum_effect = gap[t_star:].sum()                             # total causal impact over the post-period
avg_effect = gap[t_star:].mean()                            # average per-step effect
print("fitted: level=%.3f beta=%.3f" % (level_hat, beta_hat))
print("avg post-period effect = %.3f  (truth %.1f)" % (avg_effect, effect_true))
print("cumulative effect      = %.2f over %d steps" % (cum_effect, T - t_star))

fitted: level=4.812 beta=0.804
avg post-period effect = 5.928  (truth 6.0)
cumulative effect      = 237.13 over 40 steps

The numbers tell the counterfactual story directly: the model never saw the untreated post-period (it does not exist), yet by holding the fitted structural relation and offset fixed and rolling the immune control forward, it reconstructs the trajectory the target would have followed, and the gap to the actual treated trajectory recovers the +6 intervention to within sampling noise. The numeric callout reads the gap as a decision number.

Now the library pair. The whole apparatus of Code 30.4.1, the pre-period regression, the offset bookkeeping, the forward roll, the gap and cumulative sum, is exactly what the CausalImpact library packages, with the added rigor of a full Bayesian structural time-series model and posterior credible intervals rather than a point estimate. Code 30.4.2 reproduces the analysis in a few lines.

import pandas as pd
from causalimpact import CausalImpact     # pip install pycausalimpact

# Same target and control; CausalImpact wants the target as the first column.
df = pd.DataFrame({"y": target, "control": control})
pre_period  = [0, t_star - 1]             # fit the structural time-series model here
post_period = [t_star, T - 1]             # estimate the counterfactual + effect here

ci = CausalImpact(df, pre_period, post_period)   # fits a Bayesian structural time-series model
print(ci.summary())                              # average + cumulative effect with credible intervals

Posterior inference {CausalImpact}

                          Average            Cumulative
Actual                    95.9               3835.6
Prediction (s.d.)         89.9 (0.4)         3597.9 (15.8)
95% CI                    [89.1, 90.7]       [3563, 3632]

Absolute effect (s.d.)    6.0 (0.4)          237.7 (15.8)
95% CI                    [5.2, 6.8]         [203, 272]

Posterior prob. of a causal effect: 99.9%

Read the three blocks together. Code 30.4.1 built abduction (pre-period fit), action (the implicit "no intervention" edit), and prediction (forward roll) by hand, recovering the +6 effect. Code 30.4.2 reproduced the same effect in three lines with full posterior intervals, the library handling the Bayesian structural time-series model, the control regression, and the credible-interval arithmetic internally. The line-count reduction from roughly 25 hand-written lines to three is the usual library dividend, but the deeper lesson is in the intervals: the from-scratch model gave a point estimate that looked certain, while the library makes the model's uncertainty explicit, and neither can ever cross the wall of the fundamental problem of causal inference, because the $89.9$ counterfactual was imputed, never measured.

6. Temporal Knowledge Graph Embeddings Advanced

The causal and counterfactual tools of this chapter assume a world whose entities and relations are described by numerical time series: a drug dose, a policy indicator, an outcome measurement. Many high-value temporal reasoning tasks, however, have a different structure: the world is a collection of named entities, typed relations between them, and facts that hold only for certain time intervals. A company is headquartered somewhere starting in a particular year. A person holds an office for a term. A drug interaction is valid until new evidence supersedes it. This relational, time-stamped view of the world is the setting of temporal knowledge graphs (TKGs), and embedding them in vector spaces that respect temporal validity is the problem this subsection addresses.

A temporal knowledge graph is a set of quadruples $(s, r, o, \tau)$ where $s$ is the subject entity, $r$ the relation, $o$ the object entity, and $\tau$ a time annotation. The annotation can be a point, an interval $[t_{\text{start}}, t_{\text{end}}]$, or a half-open interval for facts still valid at query time. A concrete example: $(\text{SpaceX},\, \texttt{headquartered\_in},\, \text{Texas},\, [2019, \text{present}])$. Given a query of the form $(\text{SpaceX},\, \texttt{headquartered\_in},\, ?,\, 2022)$, the task of temporal link prediction is to rank all candidate object entities by the probability that the triple holds at that specific time. The temporal dimension adds two difficulties absent from static KG embedding: the same entity can have different embeddings at different times (a nation's leadership in 1990 versus 2020 implies different downstream facts), and some facts are periodic (seasonal disease prevalence) while others are monotone drifts (cumulative patents held). A single learned embedding per entity cannot capture either.

TTransE: Time-Dependent Translation

The simplest extension of TransE to the temporal setting adds a learned time embedding $\boldsymbol{\tau}_t \in \mathbb{R}^d$ for each time step $t$ and modifies the scoring function to

where $\mathbf{h}$, $\mathbf{r}$, $\mathbf{t}$ are the subject, relation, and object embeddings (identical to TransE) and $\boldsymbol{\tau}_t$ is the additive time shift. The time embeddings can be learned independently (one vector per discrete time step) or parameterized as $\boldsymbol{\tau}_t = \mathbf{W} \sin(\boldsymbol{\omega} t + \boldsymbol{\phi})$ for a sinusoidal decomposition that generalizes to unseen times. TTransE is simple and interpretable but inherits TransE's limitation: the relation semantics are assumed time-stationary. A relation like "is a subsidiary of" might change its algebraic role in embedding space over decades of corporate restructuring, and the additive $\boldsymbol{\tau}_t$ cannot capture that.

TeRo: Temporal Rotation in Complex Space

TeRo (Temporal Rotation) embeds entities and relations in the complex plane $\mathbb{C}^{d/2}$ and models temporal evolution as element-wise phase rotation. Each entity $e$ has a base embedding $\mathbf{e} \in \mathbb{C}^{d/2}$, and its embedding at time $t$ is

where $\boldsymbol{\tau}_t \in \mathbb{R}^{d/2}$ is a learned time-dependent phase vector and $\odot$ denotes element-wise multiplication. The relation $r$ is also a complex vector, and the scoring function is the RotatE distance after time rotation:

Phase rotation has two properties that match the structure of temporal facts. First, it is periodic: $\exp(i \cdot \boldsymbol{\tau}_t)$ returns to the same value whenever $\boldsymbol{\tau}_t$ advances by $2\pi$, naturally modeling seasonal or cyclically recurring facts. Second, it is bounded (all rotated vectors lie on the unit circle in each dimension), which prevents the embedding magnitude from exploding over long time horizons, a failure mode of purely additive methods. TeRo outperforms TTransE on the ICEWS and GDELT temporal KG benchmarks and is the recommended starting point for temporal link prediction tasks where the data includes periodic patterns.

TLogic: Symbolic Temporal Rules

TLogic (2022) takes a different stance: instead of learning vector embeddings, it learns symbolic temporal Horn clauses from the TKG. A temporal Horn clause has the form

meaning: if entity $X$ stands in relation $r_1$ to entity $Y$ at time $t$, and $Y$ stands in relation $r_2$ to $Z$ at time $t + \delta_1$, then $X$ stands in relation $r_3$ to $Z$ at time $t + \delta_2$. A concrete instance: "if $X$ is employed by $Y$ at $t$ and $Y$ is located in city $C$ at $t$, then $X$ is located in $C$ at $t$." TLogic mines such rules from the empirical co-occurrence of quadruples across the training set, scores each rule by confidence and temporal consistency, and answers link prediction queries by rule chaining rather than vector similarity. Its strength is interpretability: every prediction comes with an explicit rule chain that a domain expert can inspect and override. Its limitation is coverage: if the query does not match any extracted rule pattern, TLogic produces no prediction, unlike embedding methods that always return a ranking.

"""TeRo temporal knowledge graph embedding: minimal training loop.

Entities: integer ids 0..n_entities-1
Relations: integer ids 0..n_relations-1
Time steps: integer ids 0..n_times-1

Each fact is a quadruple (subject, relation, object, time).
"""
import torch
import torch.nn as nn
import torch.optim as optim

class TeRo(nn.Module):
    def __init__(self, n_entities: int, n_relations: int, n_times: int, dim: int = 64):
        super().__init__()
        # Base entity and relation embeddings in complex space (stored as real pairs)
        self.entity_re = nn.Embedding(n_entities, dim)
        self.entity_im = nn.Embedding(n_entities, dim)
        self.relation_re = nn.Embedding(n_relations, dim)
        self.relation_im = nn.Embedding(n_relations, dim)
        # Learned time phase: one phase vector per time step
        self.time_phase = nn.Embedding(n_times, dim)
        nn.init.uniform_(self.time_phase.weight, -0.5, 0.5)

    def _rotate(self, e_re: torch.Tensor, e_im: torch.Tensor,
                phase: torch.Tensor):
        """Apply element-wise rotation: (e_re + i*e_im) * exp(i*phase)."""
        cos_p, sin_p = torch.cos(phase), torch.sin(phase)
        return e_re * cos_p - e_im * sin_p, e_re * sin_p + e_im * cos_p

    def score(self, s: torch.Tensor, r: torch.Tensor,
              o: torch.Tensor, t: torch.Tensor) -> torch.Tensor:
        """Return the negative L2 distance (higher = more plausible)."""
        phase = self.time_phase(t)
        # Rotate subject and object embeddings by the time phase
        sh_re, sh_im = self._rotate(self.entity_re(s), self.entity_im(s), phase)
        oh_re, oh_im = self._rotate(self.entity_re(o), self.entity_im(o), phase)
        # Complex relation
        r_re, r_im = self.relation_re(r), self.relation_im(r)
        # Score: -||s_t * r - o_t|| in complex space
        diff_re = sh_re * r_re - sh_im * r_im - oh_re
        diff_im = sh_re * r_im + sh_im * r_re - oh_im
        dist = (diff_re ** 2 + diff_im ** 2).sum(dim=-1).sqrt()
        return -dist

    def forward(self, pos: torch.Tensor, neg: torch.Tensor) -> torch.Tensor:
        """Margin ranking loss over a positive and a negative quadruple batch."""
        s_p, r_p, o_p, t_p = pos[:, 0], pos[:, 1], pos[:, 2], pos[:, 3]
        s_n, r_n, o_n, t_n = neg[:, 0], neg[:, 1], neg[:, 2], neg[:, 3]
        pos_score = self.score(s_p, r_p, o_p, t_p)
        neg_score = self.score(s_n, r_n, o_n, t_n)
        margin = 2.0
        loss = torch.clamp(margin - pos_score + neg_score, min=0.0).mean()
        return loss


def train_tero(facts: list[tuple[int, int, int, int]],
               n_entities: int, n_relations: int, n_times: int,
               epochs: int = 200, lr: float = 1e-3) -> TeRo:
    """Train TeRo on a list of positive (s, r, o, t) quadruples.

    Negative samples are generated by randomly corrupting the object.
    """
    model = TeRo(n_entities, n_relations, n_times)
    optimizer = optim.Adam(model.parameters(), lr=lr)
    facts_t = torch.tensor(facts, dtype=torch.long)

    for epoch in range(epochs):
        # Corrupt object for negative samples
        neg = facts_t.clone()
        neg[:, 2] = torch.randint(0, n_entities, (len(facts),))
        loss = model(facts_t, neg)
        optimizer.zero_grad()
        loss.backward()
        optimizer.step()
        if (epoch + 1) % 50 == 0:
            print(f"Epoch {epoch+1}/{epochs}  loss={loss.item():.4f}")
    return model


# --- pykeen shortcut: TTransE and TeRo are built-in ---
# from pykeen.pipeline import pipeline
# result = pipeline(
#     dataset="ICEWS14",
#     model="TeRo",
#     model_kwargs={"embedding_dim": 200, "num_time_steps": 365},
#     training_kwargs={"num_epochs": 500, "batch_size": 1024},
# )
# print(result.metric_results.to_df())

from pykeen.pipeline import pipeline

result = pipeline(
    dataset="ICEWS14",          # built-in temporal KG: 14k entities, 230 relations, 365 time steps
    model="TeRo",
    model_kwargs={"embedding_dim": 200},
    training_kwargs={"num_epochs": 500, "batch_size": 1024},
    evaluation_kwargs={"batch_size": 64},
    random_seed=42,
)
print(result.metric_results.to_df())   # MRR, Hits@1, Hits@3, Hits@10

Temporal knowledge graphs connect to the broader architecture of this book in three directions. In Chapter 31, TKG embeddings serve as a structured external memory for temporal agents: instead of storing raw text observations, an agent can store extracted quadruples and retrieve them by (entity, relation, time) query, gaining a semantically structured alternative to unstructured vector retrieval. In Chapter 35 on financial event reasoning, TKGs represent corporate event chains where a merger at time $t$ changes the set of valid employment and ownership facts at $t' > t$. In Chapter 36 on temporal question answering, temporal link prediction is the backbone of systems that answer queries like "who led organization X during period Y?" The key limitation that ChronoKG documents, poor extrapolation to future timestamps, means that TKGs are currently most reliable as a memory of the recorded past and weakest as a predictive model of the future, a distinction that any temporal AI system must design around explicitly.

7. Exercises

Three exercises consolidate the section: a conceptual one on the ladder, an implementation one extending the worked code, and an open-ended one on the limits.

1. (Conceptual) Why abduction is the extra rung. Consider the SCM $Y = 2A + U$ with $U \sim \mathcal{N}(0, 1)$. A unit took $A = 3$ and we observed $Y = 7$. (a) Compute the interventional quantity $\mathbb{E}[Y \mid \operatorname{do}(A = 1)]$. (b) Compute the counterfactual $\mathbb{E}[Y_{A=1} \mid A = 3, Y = 7]$ using abduction-action-prediction. (c) Explain in one or two sentences why the two answers differ and what real-world question each one answers, connecting your explanation to the interventional-versus-counterfactual distinction of Section 30.3 and subsection one.
2. (Implementation) Sensitivity to the control. Starting from Code 30.4.1, contaminate the control series so it is not immune to the intervention: add a fraction $\rho \cdot \text{effect\_true}$ of the intervention into control[t_star:] for $\rho \in \{0, 0.25, 0.5, 1.0\}$. Re-fit and report how the estimated average post-period effect changes with $\rho$. Show that as the control absorbs more of the intervention, the estimated effect collapses toward zero, and write one sentence relating this to the over-trust risk of subsection four. (Optional: wrap the four runs in a loop and print a small table.)
3. (Open-ended) The unverifiable number. The fundamental problem of causal inference says the counterfactual trajectory $y_t^{(0)}$ is never observed for the treated unit. Design a validation strategy that gives you some empirical confidence in a counterfactual baseline despite this, using only data you actually have. Consider ideas such as a placebo or pre-intervention "fake intervention" test (the gap should be near zero in a period where nothing happened), backtesting the baseline on past interventions whose effects are known, or holding out control series. Discuss what each strategy does and does not certify, and connect your answer to the conformal-counterfactual coverage work referenced in the research-frontier callout.
