Volatility Modeling: ARCH, GARCH, and Stochastic Volatility

"You watched my returns and called them random, since one day told you nothing about the next. You forgot to watch their size. A storm announces itself: the calm before me is short, and once I begin to rage I rage for weeks. I never travel alone."

A Volatility Cluster That Never Travels Alone

The previous sections of this chapter modeled relationships across several series: vector autoregression in Section 6.1, cointegration and the error-correction mechanism in Section 6.3, the Granger-causal and impulse-response analysis of Section 6.2, and the dynamic factor models of Section 6.4. All of them modeled the conditional mean. We now turn to the second moment. The running finance dataset of Part II, an equity-index return series, has a property that the mean-focused theory of Sections 6.1 through 6.4 cannot represent at all: its returns pass every test for serial uncorrelatedness while failing, spectacularly, every test for independence. The resolution is to model the variance as a function of the past, and that is the entire subject of this closing section. We will use the moment symbols $\mu$, $\gamma(k)$, $\rho(k)$ and the white-noise notation $\varepsilon_t \sim \text{WN}(0, \sigma^2)$ collected in the unified notation table of Appendix A.

1. The Phenomenon: Uncorrelated but Not Independent Beginner

Let $p_t$ be the price of an asset and $r_t = \ln p_t - \ln p_{t-1}$ its log return. Decades of empirical study, summarized in a famous list of "stylized facts," establish that real return series share a handful of features no random walk reproduces. Returns are very nearly uncorrelated: $\rho_r(k) \approx 0$ for all $k \ge 1$, so the level of tomorrow's return cannot be predicted from today's, which is the kernel of truth in the efficient-market intuition. Yet the squared returns and the absolute returns are strongly and persistently autocorrelated: $\rho_{r^2}(k) > 0$ and decays slowly over many lags. That single contrast, $\rho_r(k) \approx 0$ while $\rho_{r^2}(k) > 0$, is the empirical signature of volatility clustering, and it is logically impossible for an independent series, because if $r_t$ were independent of its past then any function of it, including $r_t^2$, would be too. Uncorrelated does not mean independent, and the gap between the two is exactly where volatility lives.

Three further stylized facts complete the picture and shape the models. First, heavy tails: the unconditional distribution of returns has far more mass in its extremes than a Gaussian, so "six-sigma" days occur far more often than a normal model permits. Second, the leverage effect: negative returns raise future volatility more than positive returns of the same size, an asymmetry a symmetric variance model cannot capture, named for the original explanation that a falling stock price raises a firm's debt-to-equity ratio and so its risk. Third, volatility persistence: shocks to variance decay slowly, so the conditional variance has long memory even though the returns do not. There is a subtle relationship among these facts worth pausing on. Heavy tails are partly a consequence of volatility clustering rather than an independent assumption: a process that mixes calm low-variance days with turbulent high-variance days has, when you pool all days together, an unconditional distribution that is a mixture of narrow and wide Gaussians, and such mixtures are leptokurtic (fat-tailed) even when each component is Gaussian. So a model that captures clustering inherits heavy tails for free, which is one reason GARCH with even Gaussian innovations already produces more realistic tails than a single normal. The table below collects these facts against what a plain random walk predicts, because the entire ARCH-GARCH program is an effort to honor this column of reality.

The diagnostic that opens any volatility study is the pair of autocorrelation functions from Section 3.3, computed once on the returns and once on the squared returns. The formal version of this eyeball test is the ARCH-LM test (Engle's Lagrange-multiplier test): regress $r_t^2$ on its own $q$ lags and test whether the $R^2$ of that regression is significantly above zero, since under the no-clustering null the squared returns are unforecastable and the regression explains nothing. A rejection is the green light to fit a volatility model, and it is the standard pre-flight check before any GARCH is estimated. Code 6.5.1 builds the running finance series and computes both correlograms from scratch, so the defining contrast is a number rather than an assertion, with the squared-return ACF standing in for the ARCH-LM regression it is algebraically tied to.

import numpy as np

def acf(x, max_lag):
    """Sample autocorrelation rho(k) for k = 1..max_lag (the estimator of Section 3.3)."""
    x = np.asarray(x, dtype=float)
    x = x - x.mean()
    denom = np.sum(x * x)                       # gamma(0) * n
    return np.array([np.sum(x[k:] * x[:-k]) / denom for k in range(1, max_lag + 1)])

# Running finance dataset: simulate returns with GARCH(1,1)-style clustering so the
# stylized facts are present by construction (a real index return series behaves the same).
rng = np.random.default_rng(7)
n = 2000
omega, alpha, beta = 0.05, 0.10, 0.88          # high alpha+beta = persistent volatility
sigma2 = np.empty(n); ret = np.empty(n)
sigma2[0] = omega / (1 - alpha - beta)          # start at the unconditional variance
for t in range(1, n):
    sigma2[t] = omega + alpha * ret[t-1]**2 + beta * sigma2[t-1]
    ret[t] = np.sqrt(sigma2[t]) * rng.standard_normal()
ret -= ret.mean()                               # work with mean-zero returns

r_acf  = acf(ret,       max_lag=10)
r2_acf = acf(ret**2,    max_lag=10)
band = 1.96 / np.sqrt(n)                         # 95% white-noise significance band
print(f"95% white-noise band: +/- {band:.3f}")
print("lag   ACF(returns)   ACF(squared returns)")
for k in range(10):
    flag = " <== significant" if r2_acf[k] > band else ""
    print(f"{k+1:3d}      {r_acf[k]:+6.3f}          {r2_acf[k]:+6.3f}{flag}")

95% white-noise band: +/- 0.044
lag   ACF(returns)   ACF(squared returns)
  1      +0.017          +0.213 <== significant
  2      -0.008          +0.190 <== significant
  3      +0.026          +0.171 <== significant
  4      -0.011          +0.158 <== significant
  5      +0.004          +0.139 <== significant
  6      +0.019          +0.121 <== significant
  7      -0.022          +0.108 <== significant
  8      +0.009          +0.097 <== significant
  9      +0.015          +0.082 <== significant
 10      -0.006          +0.071 <== significant

2. ARCH(q): Variance From Past Shocks Beginner

Robert Engle's 1982 ARCH model (autoregressive conditional heteroskedasticity, an econometrics Nobel in 2003) is the first formalization of the conditioning idea. It posits that the conditional variance is a constant plus a weighted sum of recent squared shocks. With $r_t = \varepsilon_t$ and $\varepsilon_t = \sigma_t z_t$, $z_t \sim \text{i.i.d.}(0,1)$, the ARCH($q$) variance equation is

with $\omega > 0$ and every $\alpha_i \ge 0$ so the variance can never go negative. The mechanism is exactly the clustering of subsection one: a large shock $\varepsilon_{t-1}$ enters $\sigma_t^2$ through its square, inflating the variance of the next return, which makes a second large move likely, which inflates the variance again. A big move begets a big move, a calm stretch begets calm, and the model manufactures the slow decay of $\rho_{r^2}(k)$ that the data demand. The word "autoregressive" in the name is literal: ARCH($q$) is an AR($q$) model for the squared shocks, because $\varepsilon_t^2 = \sigma_t^2 + (\varepsilon_t^2 - \sigma_t^2)$ rearranges into $\varepsilon_t^2 = \omega + \sum_i \alpha_i \varepsilon_{t-i}^2 + \nu_t$ with a mean-zero error $\nu_t$, an AR($q$) in $\varepsilon_t^2$. The Yule-Walker and correlogram machinery of Section 3.3 therefore applies directly to the squared series, which is why the squared-return ACF of Output 6.5.1 is the natural identification tool.

Notice that an ARCH process is unconditionally homoskedastic even while being conditionally heteroskedastic: averaged over all time the variance is the constant $\bar\sigma^2$, but conditioned on the recent past it moves. This reconciliation is why the returns can look stationary in the long run (a single unconditional variance exists) while being violently time-varying in the short run, and it is the same calm-on-average, turbulent-in-detail behavior the mixture argument of subsection one used to explain heavy tails. For the model to define a stationary process with a finite unconditional variance, the persistence must be bounded: $\sum_{i=1}^q \alpha_i < 1$. When it holds, the long-run (unconditional) variance is the level the recursion settles to when every $\varepsilon_{t-i}^2$ is replaced by its mean $\bar\sigma^2$, giving

the value the simulation in Code 6.5.1 used to initialize its variance. The numeric example below traces the recursion through a shock so the begets-a-big-move mechanism is concrete.

That last sentence is the whole case for the next subsection. Real volatility shocks decay over weeks, so an ARCH model that matches them needs $q$ in the teens, and estimating a dozen non-negative, summing-to-less-than-one coefficients is fragile and data-hungry. The fix is the same parsimony move that turned a long MA into a short ARMA in Section 5.3: add a feedback term.

3. GARCH(p,q): Parsimony Through Variance Feedback Intermediate

Tim Bollerslev's 1986 generalization, GARCH, adds lagged conditional variances to the recursion. The conditional variance now depends on both past squared shocks and its own past values,

with $\omega > 0$, $\alpha_i \ge 0$, $\beta_j \ge 0$. The $\beta_j$ terms are the masterstroke. Just as an ARMA squeezes an infinite MA into a short rational form, a GARCH squeezes the long ARCH into a short feedback recursion: substituting the equation into itself repeatedly shows that a GARCH(1,1) is an ARCH($\infty$) with geometrically decaying weights $\alpha_1 \beta_1^{\,k}$. Two parameters, $\alpha_1$ and $\beta_1$, reproduce the weeks-long decay that ARCH needed a dozen $\alpha_i$ to approximate. The parsimony argument of Section 5.3 returns verbatim, one level up, on the variance instead of the mean.

The GARCH(1,1) is the undisputed workhorse of empirical finance, and its single equation deserves to be read carefully:

The coefficient $\alpha_1$ measures how strongly the most recent surprise moves volatility (the reaction), $\beta_1$ measures how much of yesterday's volatility carries into today (the persistence or memory), and their sum $\alpha_1 + \beta_1$ is the total persistence, the rate at which a volatility shock decays. The unconditional variance generalizes the ARCH formula to $\bar\sigma^2 = \omega / (1 - \alpha_1 - \beta_1)$, which is finite and the process is covariance-stationary precisely when $\alpha_1 + \beta_1 < 1$. On real daily equity data $\alpha_1 + \beta_1$ is routinely above $0.95$, meaning shocks decay only a few percent per day and volatility regimes last for months; the boundary case $\alpha_1 + \beta_1 = 1$ is the integrated GARCH (IGARCH), the volatility analogue of the unit root from Section 3.2, where shocks to variance never fully die.

It is worth seeing precisely why the GARCH(1,1) is an ARCH($\infty$), because that single algebraic fact is the entire parsimony argument and it mirrors the ARMA-to-MA expansion of Section 5.3. Write the recursion and substitute it into itself once: $\sigma_t^2 = \omega + \alpha_1 \varepsilon_{t-1}^2 + \beta_1 (\omega + \alpha_1 \varepsilon_{t-2}^2 + \beta_1 \sigma_{t-2}^2)$. Repeating the substitution indefinitely peels off one $\beta_1$ factor each time and yields

an ARCH($\infty$) whose weights $\alpha_1 \beta_1^{k}$ decay geometrically in the lag $k$. So $\beta_1$ does not add a new kind of dependence; it efficiently encodes an infinite, geometrically fading dependence on all past squared shocks, using one parameter to do what an ARCH would need infinitely many $\alpha_i$ to approximate. The closer $\beta_1$ is to one, the slower the geometric decay and the longer the volatility memory, which is the precise sense in which $\beta_1$ is the persistence knob.

The symmetric GARCH(1,1) still misses one stylized fact: the leverage effect, the empirical asymmetry whereby a $-3\%$ day raises tomorrow's volatility more than a $+3\%$ day. Because the recursion uses $\varepsilon_{t-1}^2$, it is blind to the sign of the shock. Two standard variants restore the asymmetry. The GJR-GARCH (Glosten, Jagannathan, Runkle) adds a term that switches on only for negative shocks, $\sigma_t^2 = \omega + \alpha_1 \varepsilon_{t-1}^2 + \gamma\, \varepsilon_{t-1}^2 \mathbb{1}[\varepsilon_{t-1} < 0] + \beta_1 \sigma_{t-1}^2$, so a down-move gets the extra coefficient $\gamma > 0$. The EGARCH (Nelson) models $\ln \sigma_t^2$ instead of $\sigma_t^2$, which both guarantees positivity without sign constraints on the parameters and lets the sign of the shock enter linearly, giving a smooth asymmetric response. The table below lays the family out so the variant names stop feeling like alphabet soup.

4. Stochastic Volatility: Giving Variance a Life of Its Own Advanced

GARCH has one philosophically restrictive feature: its conditional variance is deterministic given the past. Once you know the history of returns, $\sigma_t^2$ is computed exactly from the recursion, with no randomness of its own. There is a single source of noise, $z_t$, doing double duty for both the return and, through $\varepsilon_{t-1}^2$, the variance. Stochastic volatility (SV) models drop this restriction and let the log-variance follow its own latent stochastic process, driven by a second, independent noise source. The canonical discrete-time SV model is

where $h_t = \ln \sigma_t^2$ is the unobserved log-variance, $z_t \sim \text{i.i.d.}(0,1)$ drives the return, and $\eta_t \sim \mathcal{N}(0, \sigma_\eta^2)$ is an independent volatility innovation. The log-variance $h_t$ is itself an AR(1), the exact mean-reverting recursion of Section 5.1, now living one layer beneath the observable returns. The contrast with GARCH is sharp and worth stating plainly: in GARCH the variance is a known function of past returns, whereas in SV the variance is a hidden state that we can only infer, never observe, even with the entire return history in hand.

The parameters carry clear meaning. The autoregressive coefficient $\phi$ is the persistence of log-volatility (typically $0.95$ to $0.99$ on daily data, the SV echo of GARCH's high $\alpha_1 + \beta_1$), $\mu$ sets the average log-variance, and $\sigma_\eta$, the standard deviation of the volatility innovation, is the "volatility of volatility," a quantity GARCH has no parameter for at all because its variance carries no independent noise. That extra parameter is exactly what lets SV reproduce the rapid, seemingly causeless jumps in market volatility that a GARCH, tethered to the squared returns, can only react to after the fact. The price of the extra realism is paid at inference time.

That structure, a latent state evolving by its own dynamics and observed only through a noisy nonlinear measurement, is precisely the state-space model that Chapter 7 is built around. The SV model is a nonlinear, non-Gaussian state-space model: the state is $h_t$, the transition is the AR(1), and the observation $r_t = \exp(h_t/2) z_t$ is nonlinear in the state. The Kalman filter of Chapter 7 assumes linear-Gaussian dynamics and so does not apply directly; estimating SV requires the nonlinear filtering tools that chapter introduces, chiefly the particle filter (sequential Monte Carlo), which represents the distribution of the hidden volatility by a swarm of weighted samples propagated forward through the AR(1) and reweighted by each new return. A common alternative linearizes the model by squaring and taking logs, $\ln r_t^2 = h_t + \ln z_t^2$, which turns the observation equation linear in $h_t$ at the cost of a strongly non-Gaussian, heavily left-skewed measurement noise $\ln z_t^2$, after which a quasi-maximum-likelihood Kalman filter or a Bayesian Markov-chain Monte Carlo sampler (the route the pymc and stan ecosystems take) estimates the path and parameters. Either way, this is the cost of SV's extra realism: GARCH is fit by a one-line likelihood recursion, while SV needs simulation-based or Bayesian inference. The payoff is a model whose variance can be genuinely surprised, which matches markets where volatility jumps for reasons the return history alone never anticipated.

5. Uses: Risk, Option Pricing, and Why Points Are Not Enough Intermediate

A volatility model earns its keep through three uses, and all three share a moral that closes this chapter and opens the next part of the book. Before the uses, one caution about estimating returns at all: the conditional mean and conditional variance are fit jointly, and the standard practice is to model the mean with a small ARMA (often just a constant or zero, since daily returns are nearly mean-zero) and the variance with GARCH on the mean-model residuals. Misspecifying the mean leaks into the variance, because the residuals the GARCH consumes are only as clean as the mean model that produced them, which is why the running example fixes mean="Zero": the returns were constructed mean-zero, so no mean model is needed and the entire signal is in the variance. The first use is risk measurement. The Value-at-Risk at confidence $1 - \alpha$ over one period is the loss threshold exceeded with probability only $\alpha$. For returns $r_t = \sigma_t z_t$, it is

where $q_\alpha$ is the $\alpha$-quantile of the innovation distribution of $z_t$ (for a Gaussian, $q_{0.01} = -2.326$, so the $99\%$ VaR is $2.326\,\sigma_t$). The crucial point is that VaR is proportional to the conditional volatility $\sigma_t$, which is exactly what GARCH forecasts: a risk number that breathes with the market, tightening in calm and widening in turmoil, instead of the static historical-volatility number that is always fighting the last war. The companion measure, Expected Shortfall (the average loss beyond the VaR threshold), is likewise a multiple of $\sigma_t$, so a fitted GARCH delivers a whole moving risk dashboard from one recursion.

The second use is option pricing. The Black-Scholes formula takes volatility as a constant input, but markets price options as if volatility varies with strike and maturity (the "volatility smile" and its term structure). GARCH's multi-step variance forecast $\hat\sigma_{t+h}^2$ from subsection three provides exactly the forward-looking, mean-reverting variance term-structure that smarter option models need: the average variance over the life of an option is the average of the term structure, so a GARCH that says "volatility is high now but reverts over six weeks" prices a one-month option differently from a six-month option, which is the maturity dimension of the smile. Stochastic-volatility models underlie the Heston model that the derivatives industry uses to fit the smile in closed form. The third use, and the one that points forward, is the recognition that for a risky series a single point forecast is the wrong deliverable. The best forecast of tomorrow's return is approximately zero, which is useless; the useful forecast is the whole conditional distribution, $r_{t+1} \sim \mathcal{N}(0, \hat\sigma_{t+1}^2)$ or its heavy-tailed cousin, from which VaR, Expected Shortfall, option prices, and probabilistic scenarios all flow.

6. Worked Example: GARCH(1,1) From Scratch and Through arch Advanced

We now fit a GARCH(1,1) to the running finance returns of Code 6.5.1 two ways: from scratch, by coding the variance recursion and maximizing its Gaussian log-likelihood with a general optimizer, and through the production arch library. The pair is the point of the section: the from-scratch fit shows you that a GARCH is just a one-line recursion plus a likelihood, and the library fit shows you the few lines you would actually ship. We then turn the fitted volatility into a Value-at-Risk band and a multi-step volatility forecast. Code 6.5.2 implements the negative log-likelihood and minimizes it.

import numpy as np
from scipy.optimize import minimize

def garch11_filter(params, r):
    """Run the GARCH(1,1) variance recursion; return the conditional variance path."""
    omega, alpha, beta = params
    n = len(r)
    sigma2 = np.empty(n)
    sigma2[0] = np.var(r)                        # seed at the sample variance
    for t in range(1, n):
        sigma2[t] = omega + alpha * r[t-1]**2 + beta * sigma2[t-1]
    return sigma2

def garch11_neg_loglik(params, r):
    """Gaussian negative log-likelihood of GARCH(1,1); the objective to minimize."""
    omega, alpha, beta = params
    if omega <= 0 or alpha < 0 or beta < 0 or alpha + beta >= 1:
        return 1e10                             # enforce positivity + stationarity
    sigma2 = garch11_filter(params, r)
    # -2 log L (dropping constants) summed over t: log(sigma2) + r^2 / sigma2
    return 0.5 * np.sum(np.log(sigma2) + r**2 / sigma2)

# Fit on the running finance returns built in Code 6.5.1 (variable `ret`).
start = np.array([0.05, 0.10, 0.85])            # omega, alpha, beta starting guess
res = minimize(garch11_neg_loglik, start, args=(ret,),
               method="Nelder-Mead", options={"xatol": 1e-8, "fatol": 1e-8})
omega_hat, alpha_hat, beta_hat = res.x
uncond = omega_hat / (1 - alpha_hat - beta_hat)
print(f"omega = {omega_hat:.4f}   alpha = {alpha_hat:.4f}   beta = {beta_hat:.4f}")
print(f"persistence  alpha+beta = {alpha_hat + beta_hat:.4f}")
print(f"unconditional variance   = {uncond:.4f}   (sample var = {np.var(ret):.4f})")
print(f"shock half-life          = {np.log(0.5)/np.log(alpha_hat + beta_hat):.1f} days")

omega = 0.0492   alpha = 0.0974   beta = 0.8821
persistence  alpha+beta = 0.9795
unconditional variance   = 2.4001   (sample var = 2.3958)
shock half-life          = 33.4 days

The from-scratch fit is transparent but hand-rolled. In production you would reach for arch, which fits the same model with robust standard errors, a choice of innovation distributions, and built-in forecasting, in a handful of lines. Code 6.5.3 is the library pair, and it lands on the same parameters.

from arch import arch_model

# The same GARCH(1,1) fit, the production way. mean="Zero" because returns are mean-zero.
am = arch_model(ret, mean="Zero", vol="GARCH", p=1, q=1, dist="normal")
fit = am.fit(disp="off")
print(fit.params.round(4).to_string())

# Conditional volatility and a one-step 99% Value-at-Risk band.
sigma = fit.conditional_volatility               # sqrt(sigma2_t), the fitted vol path
q01 = -2.326                                      # 1% Gaussian quantile
VaR99 = -sigma * q01                              # 99% VaR = 2.326 * sigma_t

# Multi-step variance forecast (reverts toward the long-run variance).
fc = fit.forecast(horizon=10, reindex=False)
var_path = fc.variance.values[-1]                 # sigma2 forecasts for h = 1..10
print("10-step volatility forecast:", np.round(np.sqrt(var_path), 3))
print(f"latest conditional vol     : {sigma[-1]:.3f}")
print(f"latest 99% 1-day VaR       : {VaR99[-1]:.3f}  (loss exceeded 1 day in 100)")

omega    0.0495
alpha[1] 0.0971
beta[1]  0.8826
10-step volatility forecast: [1.593 1.589 1.585 1.581 1.578 1.575 1.572 1.569 1.567 1.565]
latest conditional vol     : 1.598
latest 99% 1-day VaR       : 3.717  (loss exceeded 1 day in 100)

The final piece is to see the conditional volatility and its VaR band against the returns, which is the picture a risk manager actually reads. Code 6.5.4 computes the band from scratch and backtests its coverage, the honest test of any VaR model.

# Backtest the 99% VaR: the fraction of days where the actual loss exceeded the band
# should be close to 1% if the model is well calibrated (a "VaR exceedance" test).
sigma_scratch = np.sqrt(garch11_filter(res.x, ret))   # from-scratch vol path
VaR99_scratch = 2.326 * sigma_scratch                  # 99% one-day VaR each day
losses = -ret                                          # a loss is a negative return
exceed = losses > VaR99_scratch                        # days the loss broke the band
rate = exceed.mean()
print(f"VaR exceedance rate: {rate:.3%}   (target 1.00% for a 99% VaR)")
print(f"exceedances: {exceed.sum()} of {len(ret)} days")

# Volatility forecast term structure from the fitted parameters (Key-Insight formula).
sig2_now = sigma_scratch[-1]**2
ab = alpha_hat + beta_hat
fc_var = [uncond + ab**(h-1) * (omega_hat + alpha_hat*ret[-1]**2 + beta_hat*sig2_now - uncond)
          for h in range(1, 11)]
print("term structure of vol (scratch):", np.round(np.sqrt(fc_var), 3))

VaR exceedance rate: 1.05%   (target 1.00% for a 99% VaR)
exceedances: 21 of 2000 days
term structure of vol (scratch): [1.598 1.594 1.59  1.586 1.583 1.58  1.577 1.574 1.571 1.569]

Step back and notice what the volatility model delivered that no mean model in this chapter could. The returns themselves were unforecastable in level, white noise by every test in Output 6.5.1, so the conditional-mean machinery of Sections 6.1 through 6.4 had nothing to predict. Yet by modeling the conditional variance we extracted a strongly forecastable quantity, turned it into a moving risk band that passed an honest backtest, and produced a volatility term structure for option pricing. The deliverable was never a point; it was a distribution that breathes with the market. That shift, from forecasting the number to forecasting the distribution, is the bridge from Part II's classical models to the probabilistic deep forecasters of Chapter 14 and the uncertainty quantification of Chapter 19, and it is the note on which this chapter, and Part II's classical arc, closes.
